Specifications

• Mfr Part Number: CA-1H8-00M1WN-00

• Case Type: ATX Mid Tower

• Color: Black

• Material: SPCC

• M/B Type: ATX (12.0" x 9.6"), MicroATX (9.6" x 9.6"), Mini ITX (6.7" x 6.7")

• Drive Bays: 3
  • Internal Bay: 3x 3.5" or 2.5" (w/ HDD Cage)

• Expansion Slots: 8 + 2

• Cooling System:
  • Front (intake): 1x 140 x 140 x 25 mm Riing LED Blue Fan (1400rpm, 28dBA), (1000rpm, 22dBA with LNC)

  • Rear (Exhaust): 1x 140 x 140 x 25 mm Riing LED Blue Fan (1400rpm, 28dBA), (1000rpm, 22dBA with LNC)

  • LCS Upgradable: Supports 1/2", 3/8", 1/4" water tube

• Side Windows: Yes, 2x 4mm Tempered Glass (Left & Right)

• Front I/O Panel: 2x USB 3.0 Ports, 2x USB 2.0 Ports, 1x HD Audio

• Maximum Compatibility:
  • VGA Card Length: 278 mm (with HDD rack), 420 mm (w/o HDD rack)

  • CPU Cooler Height: 180mm

  • PSU length limitation: 180 mm (w/ one Bottom Fan), 220 mm (w/o Bottom Fan)

• Power Supply: None, Supports Standard PS2 PSU (optional)

• Dimensions (WxDxH): 9.8 x 20.1 x 19.5 inch / 250.0 x 511.0 x 497.0 mm

• Weight: 21.8 lbs / 9.9 kg
