Specifications

• Mfr Part Number: SYS-5038AD-T
• Motherboard: Super C7Z87-OCE
• Processor: LGA1150
  • Supports 4th Generation Intel Core i7/ i5/ i3 Processors
• Chipset: Intel Z87
• Memory: 4x 240pin DDR3-3000/ 2800/ 2600/ 2400/ 2200/ 2133/ 1600 DIMM Slots, Non-ECC, Unbuffered, Max Capacity of 32GB
• Slots: 3x PCI-Express 3.0 x16 Slots (run at x16 or x8/x8 or x8/x4/x4), 3x PCI-Express 2.0 x4 Slots (run at x1)
• SATA: 8x SATA3 Ports, Six via PCH Support RAID 0, 1, 5, 10, Two via ASM1061
• Audio: Realtek ALC1150 7.1-Channel High Definition Audio CODEC
• LAN: Intel i217LM and Intel i210AT Gigabit Ethernet Controllers
• Drive Bays: 2x 3.5" Hot-swap HDD Bays, 4x 2.5" Hot-swap HDD Bays, 3x 3.5" Fixed HDD Bays, 2x 5.25" Peripheral Drive Bays
• Ports: 8x USB 3.0 Ports (4 rear, 4 via headers), 6x USB 2.0 Ports (2 rear, 4 via headers), 1x VGA Port, 1x DVI Port, 1x HDMI Port, 1x Thunderbolt Port, 2x RJ45 LAN Ports, Audio I/O Jacks
• Form Factor: Mid-Tower
• Power Supply: 900W 80 PLUS Gold Certified AC Multi Output Power Supply w/ PMBus
• System Cooling: 1x 120mm Rear Exhaust Fan w/ Optimal Fan Speed Control; Supports Liquid Cooling
• Front Panel:
  • Buttons: Power On/Off
  • LEDs: Power, Hard Drive Activity, Network Activity, System Overheat
• Color: Black
• Dimension (WxDxH): 7.60 x 20.68 x 16.70 inch / 193.0 x 525.3 x 424.0 mm
• Gross Weight: 40.0 lbs / 18.1 kg
• RoHS Compliant
