Specifications

• Mfr Part Number: ST14000NM0048
• Capacity: 14TB
• Spindle Speed: 7200 RPM
• Cache: 256 MB
• Interface: 12Gb/s SAS
• Max. Sustained Transfer Rate OD: 261, 249 MB/s
• Average Latency: 4.16 ms
• Random Read  4K QD16 WCD: 170 IOPS
• Random Write 4K QD16 WCD: 418 IOPS
• Shock:
  • Operating (Read/Write): 70/40Gs @ 2ms
  • Non-operating: 250Gs @ 2ms
• Vibration:
  • Non-operating: 2.27Gs @ 2Hz to 500Hz
• Power Consumption:
  • Idle Average: 5.0W
  • Max Operating, Random Read/Write 4K/16Q Power: 10.2W, 6.2W
  • Power Supply Requirements: +12V and +5V
• MTBF: 2,500,000 hours
• Dimensions (WxDxH): 4.010 x 5.787 x 1.028 inch / 101.85 x 147.00 x 26.11 mm
• Weight: 1.521 lbs / 690.0 g
