Specifications

• Mfr Part Number: ST3200FM0063
• Capacity: 3200 GB
• Form Factor: 2.5 inch
• Interface: Dual SAS 12Gb/s
• NAND Flash: eMLC
• Performance:
  • Sequential Read Peak, 128KB (Dual port/Single port): 1600/1100 MB/s
  • Sequential Write Peak, 128KB: 850 MB/s
  • Random Read Peak, 4KB QD32: 180,000 IOPS
  • Random Write Peak, 4KB QD32: 20,000 IOPS
  • Average Latency: 115 s
• Shock: 1000Gs @ 0.5ms
• Vibration: 1.98Grms @ 10Hz to 500Hz
• Power Management:
  • +5/+12V Max Start Current: 0.44/0.41 A
  • Average Sleep Power: 4.8 W
  • Configurable Power Limit Settings: 9 to 12 W
  • Average Idle Power: 5.8 W
• Thickness: 15.0 mm
• Dimensions (WxDxH): 2.760 x 3.955 x 0.591 inch / 70.10 x 100.45 x 15.00 mm
• Weight: 0.3638 lbs / 165.0 g
