Specifications

• Mfr Part Number: 11295-01-20G
• GPU:
  • Radeon RX 5500 Graphics
  • 2nd Gen 7nm GPU
  • RDNA Architecture
• Engine Clock:
  • Boost Clock: Up to 1845MHz
  • Game Clock: Up to 1737 MHz
    *Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
• Stream Processors: 1408
• Memory Size/Bus: 8GB/128 bit GDDR6
• Memory Clock: 14 Gbps Effective
• Displays: Maximum 4 Displays
• Resolution:
  • HDMI: 4096 x 2160@60Hz
  • DisplayPort1.4: 5120 x 2880@60Hz
• Interface: PCI-Express 4.0
• Output:
  • 1 x HDMI
  • 3 x DisplayPort
• BIOS Support: Dual UEFI
• API:
  • Vulkan
  • OpenGL 4.6
  • OpenCL 2.0
  • DirectX 12
  • Shader Model 6.4
• Game Index: Extreme 1080P
• Sapphire Features:
  • Power Design
  • Free Flow
  • TriXX Supported
  • TriXX Boost
  • Intelligent Fan Control
  • Precision Fan Control
  • Robust VRM Cooling
  • Robust Memory Cooling
  • Dual-X Cooling Technology
  • Tough Metal Backplate
  • PCB Layers
  • Two-Ball Bearing
  • Fan Quick Connect
  • Fuse Protection
  • Dual BIOS
• AMD Features:
  • RDNA Architecture
  • 2nd Gen 7nm GPU
  • GDDR6 Memory
  • Power Efficiency
  • PCI Express 4.0 Support
  • Video Streaming up to 8K
  • Display Port 1.4 (HBR3) / DSC
  • Radeon Software
  • Radeon Boost
  • Radeon Image Sharpening
  • Radeon Anti-Lag
  • AMD FidelityFx
  • Async Compute
  • Radeon Rays Audio + True Audio Next
  • Radeon FreeSync 2 HDR
• Cooling:
  • Dual-X Cooling
  • Dual Fan
  • Two-Ball Bearing
• Form Factor:
  • 2 slot, ATX
  • Dimension: 233 x 121.8 x 39.6 (mm)
• Power Consumption: 135W
• OS: Linux, Windows  10, Windows  7 64bit operating system required
• System Requirement:
  • Recommended 500 Watt Power Supply (Minimum 450 Watt Power Supply)
  • 1 x 8-pin Power Connector
  • PCI Express based PC is required with one X16 lane graphics slot available on the motherboard
  • Minimum 4GB of system memory. 8GB recommended
