Specifications

• Mfr Part Number: NP-L102W
• Optical:
  • Display Technology: DLP (0.45" DMD)
  • Resolution:
    • Native: WXGA 1280 x 800
    • Maximum: UXGA 1600 x 1200
  • Light Output (Lumens): 1000 Normal
  • Contrast Ratio (up to): 10,000:1
  • Lamp Life (up to): 20,000 hours
  • Screen Size (diagonal): 17.0 ~ 100.0 inch / 0.4 ~ 2.5 m
  • Throw Ratio: 1.4
  • Projection Distance: 1.7 ~ 9.8 ft / 0.5 ~ 3.0 m
  • Projector Angle: 13.8°
  • Lens:
    • Zoom: 1 ~ 1.1
    • Focus: Manual
  • Keystone Correction: Automatic +/- 40°
• Signal Compatiblity/Connectivity:
  • Scan Rate:
    • Horizontal: 15 ~ 100 kHz
    • Vertical: 50 ~ 85 Hz
  • Supported Video Standards: NTSC, NTSC4.43, PAL-M, N, B, D, G, H, I, SECAM
  • SD/HD Video Signal Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i
  • PC Signal Compatibility: VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA
  • Macintosh Compatibility: Yes
  • Input/Output Terminals:
    • RGB1(Analog): VGA 15-pin D-sub, Component video using ADP-CV 1E
    • RGB3(Digital): HDMI w/ HDCP
    • Video 1: RCA
    • Audio 1: 1/8 inch stereo
  • Audio: 2W Speaker
  • External Control: IR
  • Sync Compatibility: Separate Sync/ Composite Sync/ Sync on G
• Electrical:
  • Power Requirements: 100~240V AC, 50/60 Hz
  • Input Current: 1.2A
  • Power Consumption (Normal/ ECO Mode/ Standby/ Standby Power Saving): 110W / 72W / NA / 0.5W
• Installation Orientation: Table/Front, Table/Rear
• Regulations: USA UL60950-1 FCC Class B, Canada CSA 60950-1, NOM
• Dimensions (WxDxH): 9.4 x 1.7 x 7.0 inch / 238.0 x 44.0 x 177.0 mm
• Weight: 3.1 lbs / 1.4 kg
