Specifications

• Mfr Part Number: MLX-D12M-A20PC-R1

• Features:
  • Dual Chamber - Low-Profile Dual Chamber
  • Stylish Radiator
  • Double Tubing
  • MF120R Argb Fans
  • Wired Addressable ARGB Controller

• Socket Type:
  • Intel Socket: LGA 2066/ 2011-v3/ 2011/ 1156/ 1155/ 1151/ 1150/ 1366/ 775

  • AMD Socket: Socket AM4/ AM3+/ AM3/ AM2+/ AM2/ FM2+/ FM2/ FM1

• Radiator:
  • Material: Aluminum
  • Dimensions : 6.2 x 4.7 x 1.1 inch / 157.0 x 119.6 x 27.0 mm
• Pump:
  • Noise Level: < 15 dBA
  • Connector: 3-Pin
  • Rated Voltage: 12V DC
  • MTTF: 70,000 hrs

  • Dimensions : 3.3 x 2.8 x 2.1 inch / 83.6 x 71.8 x 52.7 mm
• Fan:
  • Quantity: 2 PCS
  • Speed: 650 ~ 2000 RPM (PWM) ±10%

  • Noise Level: 6 ~ 30 dBA

  • Air Flow: 66.7 CFM (Max)
  • Air Pressure: 2.34 mm H2O (Max)

  • MTTF: 160,000 hrs
  • Connector: 4 Pin (PWM)
  • Rated Voltage: 12V DC

  • Dimensions: 4.7 x 4.7 x 1.0 inch / 120.0 x 120.0 x 25.0 mm
