Specifications

• Mfr Part Number: SKC600/512G
• Feature
  • Remarkable performance
  • Features the latest 3D TLC NAND technology

  • Supports a full-security suite (TCG Opal, AES 256-bit, eDrive)


• Capacity: 512G
• Form Factor: 2.5 inch
• Interface: SATA Rev. 3.0 (6Gb/s) “ with backwards capability to SATA Rev 2.0 (3Gb/s)
• Controller: SM2259
• NAND Flash: 3D TLC
• Encrypted: XTS-AES 256-bit encryption
• Performance:
  • Sequential Read: up to 550MB/s
  • Sequential Write: up to 520MB/s
  • Maximum 4K Read: up to 90,000IOPS
  • Maximum 4K Write: up to 80,000IOPS
  • Vibration Operating: 2.17G Peak (7-800Hz)
  • Vibration Non-operating: 20G Peak (10-2000Hz)
• Power Consumption:
  • Idle: 0.06 W
  • Avg: 0.2 W
  • Read: 1.3 W (Max)
  • Write: 3.2 W (Max)
• MTBF: 1,000,000 hours
• TBW: 300TB
• Dimensions: 100.10 x 69.85 x 7.00 mm
• Weight: 40.0 g
