Specifications

• Mfr Part Number: ATX-PR800W

• Features:
  • 800W Power with 13.5cm black fan
  • 80+ Gold & ROHS certified
  • High stability with 5% tolerance of 5V, 3.3V & 12V output
  • High quality components and housing

  • Universal AC input by active PFC (99%PF Typical)
• Maximum Power: 800 W
• Material: Metal
• Input:
  • Voltage: 115 - 230 V
  • Frequency Range: 50 - 60 Hz
  • Current: 8A for 115VAC, 4A for 230VAC
• Type: ATX 12V

• Fan: Forced air ventilation by 1x 135mm black fan
• Output: +3.3V @ 20A, +5V @ 20A, +12V @ 66A, -12V @ 0.3A, +5Vsb @ 2.5A
• Connectors: 1x 20/24pin Main Power Connector, 1x 4/8pin + 12V & EPS Connector, 2x 6+2pin PCI-Express Connectors, 7x SATA Connectors, 4x Peripheral Connectors
• Color: Cosmic black casing
• Dimensions (WxLxH): 5.9 x 6.3 x 3.4 inch / 150.0 x 160.0 x 85.0 mm
• Weight: 5.0 lbs
