Specifications

• Mfr Part Number: CA-1E3-00M1WN-03

• Case Type: ATX Mid Tower

• Color: Black

• Material: SPCC

• M/B Type: ATX (12.0" x 9.6"), MicroATX (9.6" x 9.6"), Mini ITX (6.7" x 6.7")

• Drive Bays: 5
  • External Bay: 2x 5.25"
  • Internal Bay: 3x 3.5" or 2.5" (HDD Cage)
• Expansion Slots: 8 + 2

• Cooling System:
  • Front (Intake): 1x 140 x 140 x 25 mm Turbo Fan (1000rpm, 16dBA)

  • Rear (Exhaust): 1x 140 x 140 x 25 mm Riing LED Blue Fan (1400rpm, 28dBA; 1000rpm, 22dBA with LNC)

  • Fan Support:
    • Front: 2x 120mm or 2x 140mm or 1x 200mm

    • Top: 3x 120mm or 3x 140mm or 2x 200mm

    • Rear: 1x 120mm or 1x 140mm

    • Bottom: 2x 120mm or 2x 140mm

  • Radiator Support:
    • Front: 1x 360mm or 1x 280mm

    • Top: 1x 360mm or 1x 280mm

    • Rear: 1x 120mm or 1x 140mm

    • Bottom: 1x 120mm or 1x 140mm

  • Liquid Cooling System Upgradable: Supports 1/2", 3/8", 1/4" Water Tube

• Side Windows: Tempered Glass (4mm thickness) Window

• Front I/O Panel: 2x USB 3.0 Ports, 2x USB 2.0 Ports, 1x HD Audio

• Maximum Compatibility:
  • VGA Card Length: 278 mm (w/ HDD rack), 420 mm (w/o HDD rack)

  • CPU Cooler Height: 180 mm

  • PSU Length: 180mm (w/ Bottom Fan), 220mm (w/o Bottom Fan)

• Power Supply: None, Supports Standard PS2 Power Supply

• Dimensions (WxDxH): 9.8 x 20.3 x 19.5 inch / 250.0 x 515.0 x 497.0 mm

• Weight: 23.4 lbs / 10.6 kg
