Specifications

• Mfr Part Number: CL-P0503

• Features:
  • Excellent ratio aluminum extrusion heatsink for better heat dissipation
  • Silent operation
  • Optimized solution for low power processors
  • Tool-less clip, easy installation
• Compatibility: FM2/ FM1/ AM3+/ AM3/ AM2+/ AM2/ K8
• Rated Voltage: 12 V
• Operating Range: 10.8~13.2 V
• Start Voltage: 7 V
• Rated Current: 0.22 A
• Fan Speed: 2900 rpm ± 10%
• Air Flow: 31.52 CFM
• Air Pressure: 3.26 mmH2O
• Noise: 34.23 dBA (Max.)
• Connector: 3Pin
• Bearing: Rifle Bearing
• Life Expectancy: 40,000 Hrs
• Fan Dimension: 80.0 x 80.0 x 15.0 mm
• Heatsink Material: Aluminum Extrusion Heatsink
• Dimension: 104.7 x 80.7 x 47.6 mm
• Weight: 250.0 g
