Specifications

• Mfr Part Number: X11SCQ-L-O
• CPU: LGA1151
  • Supports 8th Generation Intel Core i7/i5/i3/Pentium/Celeron Processor
  • Support up to 95W TDP
• Chipset: Intel H310
• Memory: 2x 288pin DDR4-2666/ 2400/ 2133/ 1866/ 1600 MHz DIMM Slots, non-ECC , Unbuffered, Max Capacity of 32GB
• Slots: 1x PCI-Express 3.0 x16 Slot, 1x PCI-Express 2.0 x4 Slot, 1x PCI-Express 2.0 x1 Slot
• SATA: 4x SATA3 Ports
• Audio: 7.1 High Definition Audio CODEC
• Video: Intel HD Graphics
• LAN: Intel PHY I219LM and Intel I210-AT Gigabit Ethernet Controllers
• Ports: 6x USB 2.0 Ports (2 rear, 4 via headers), 4x USB 3.1 Ports (Type-C rear), 1xDVI-D Port, 1x HDMI Port, 1x DisplayPort, 1x Embedded DisplayPort, 2x Independent Displays, 2x RJ45 LAN Ports
• Form Factor: MicroATX, 9.6 x 9.6 inch / 24.38 x 24.38 cm
• RoHS Compliant
