Specifications

• Mfr Part Number: MPY-7501-ACAAG-US

• Features:
  • 80 PLUS Gold Certified - The 80 PLUS Gold certification guarantees a typical efficiency of 90% or higher
  • Silent and Durable LDB Fan Bearing - Silencio technology combines sealed LDB bearings with quiet fan blades, delivering a long lifetime of quiet cooling
  • Proven Thermal Resistance - Engineered to operate at full performance in temperatures up to 45°C, providing reliability in even the hottest environments
  • Flat & Flexible Cables - The MWE Gold series adopts black flat cables for better and more flexible cable management, beneficial for airflow even in smaller cases
  • High Efficiency and Stable Output - The MWE Gold ™s full-bridge design coupled with LLC, Synchronous, and DC to DC topology technologies offers reliable and stable Voltage outputs

• Type: ATX 12V V2.31
• Output Capacity: 750W

• Input
  • Voltage: 100 - 240V AC

  • Current: 12 - 6 A
  • Frequency: 50/ 60Hz

• PFC: Active PFC (>0.95 typical)
• Power Good Signal: 100 - 500 ms

• Hold Up Time: >14 ms @ 100% load

• MTBF: >100,000 Hours
• Fan: 120mm LDB Fan
• Efficiency: 90% Typically

• Protection: OVP / OPP / UVP / SCP / OTP

• Output: +3.3V @ 15A, +5V @ 15A, +12V @ 62.5A, -12V @ 0.3A, +5sb @ 2.5A
• Connectors: 1x 24pin Motherboard Connector, 1x 4+4pin CPU 12V Connector, 4x 6+2pin PCI-Express Connectors, 8x SATA Connectors, 6x 4pin Peripheral Connectors, 1x 4pin FDD Cable Connector
• Regulatory: CCC, CE, TUV-SUD, RCM, EAC, cTUVus, FCC, BSMI, CB
• Dimensions (BxLxH): 150.0 x 140.0 x 86.0 mm
