Specifications

• Mfr Part Number: SSDPEKKW512G7X1
• Capacity: 512GB
• Form Factor: M.2 22 x 80 mm
• Interface: PCI-Express NVMe 3.0 x4

• NAND Flash: TLC
• Latency: N/A
• IOPS:
  • Random Read (8GB Span): Up to 128,500 IOPS
  • Random Write (8GB Span): Up to 128,000 IOPS
• Bandwidth:
  • Sequential Read: Up to 1775 MB/s

  • Sequential Write: Up to 560 MB/s
• Vibration:
  • Operating: 2.17 GRMS (5-700Hz) Max

  • Non-operating: 3.13 GRMS (5-800Hz) Max
• MTBF: 1,600,000 Hours
• Power Consumption:
  • Active: 100 mW (typical)
  • Idle: 40 mW (typical)
