Specifications

• Mfr Part Number: CA-1L3-00M9WN-00

• Case Type: ATX Mid Tower

• Color: Exterior - Space Gray; Interior - Black

• Material: Aluminum & SPCC

• M/B Type: ATX (12.0" x 9.6"), MicroATX (9.6" x 9.6"), Mini ITX (6.7" x 6.7")

• Drive Bays: 7
  • Internal Bay: 6x 3.5" or 2.5" (HDD Cage),  1x 2.5" (HDD Bracket)

• Expansion Slots: 8 + 2

• Cooling System:
  • Front (Intake): 2x 120 x 120 x 25 mm Fan (1000rpm, 22dBA)

  • Rear (Exhaust): 1x 120 x 120 x 25 mm Fan (1000rpm, 22dBA)

  • Fan Support:
    • Front: 3x 120mm, 3x 140mm

    • Top: 3x 120mm, 2x 140mm

    • Rear: 1x 120mm

  • Radiator Support:
    • Front: 1x 360mm, 1x 420mm

    • Top: 1x 360mm, 1x 280mm

    • Rear: 1x 120mm

• Side Windows: Yes, 2x 4mm Tempered Glass (Left & Right)

• Front I/O Panel: 2x USB 3.0 Ports, 2x USB 2.0 Ports, 1x HD Audio, 1x Type-C

• Maximum Compatibility:
  • VGA Card Length: 295 mm (w/ HDD rack), 420 mm (w/o HDD rack)

  • CPU Cooler Height: 160 mm

  • PSU Length: 220mm

• Power Supply: None

• Dimensions (WxDxH): 9.3 x 20.1 x 22.0 inch / 236.0 x 510.0 x 560.0 mm

• Weight: 32.67 lbs / 14.82 kg
